Parker PP6FF6 3/8" TrueSeal™ Series White Polypropylene 45° Flare Connector, Push-To-Connect x Female UNS Thread, EPDM O-Ring, Plastic Grip Edge

Item #PP6FF6
  • Push Button Release
  • Gripping teeth available in stainless steel or with an engineered thermoplastic bite edge
  • FDA approved
  • Meets NSF-51 food contact standards
  • Gray Acetal fittings are NSF-61 listed
  • For use in the following applications: air, water, reverse osmosis, beer and wine, dispensing systems
Parker's TrueSeal™ fittings are lightweight, field attachable, and connect to tubing without the use of tools. TrueSeal™ is a robust push-to-connect fitting ideal for water treatment and harsh chemical environments. The gripping ring in TrueSeal™ is available with either a stainless steel bite edge or an engineered thermoplastic bite edge. For use with soft metal and glass tubing.

Additional Documents:

Product ColorWhite
ComplianceNSF 51
Connection TypePush-To-Connect x Female UNS Thread
MaterialPolypropylene
Maximum Media Operating Temperature225° F
Pressure Rating150 psi @ 68° F
Seal MaterialEPDM
SeriesTrueSeal™
Size3/8 in
Thread Type5/8"-18
Type of product45° Flare Connector
